Cup Filling System

Cup Filling System
Cup Filling System
Product Code : CFM-01
Brand Name : IKON PACKAGING MACHINERIES
Product Description

Being a most trustworthy entity in the industry, we are engaged in manufacturing and exporting a best quality of Cup Filling System. This machine is highly praised by for filling the packs with different kinds of rice, sugar, pulses, tea, spices, sugar, milk powder and candies. Our machine is engineered by using the finest quality materials at our technically advanced manufacturing unit by maintaining the industry laid standards. This Cup Filling System is available at a pocket friendly price.

Features:

  • Superb strength
  • Compact design
  • Low power consumption




Three Models to Choose From :

  • CC-306 (With Suction Motor)
  • CC-307 (With Suction Motor)
  • CC-308 ( With Cup Filling System)

Features :

  • Cup Filling System
  • Piston pump filling
  • Convenient to adjust bag length.
  • Extremely high accuracy filling is achieved through precision piston pump.
  • Equipped with Germany imported photocell sensor to ensure high accuracy of bag forming.
  • Equipped with Japan imported high quality thermostat, providing fast heating performance and long service life.
  • Machine parts contacting with products are manufacture from stainless steel that meets sanitation standards.
  • Equipped with anti-drip device to prevent contamination caused by sticky flow pf liquid.

Applicable Products :

  • For packaging liquid and paste products, such as Shampoo, Ketchup, Toothpaste, Cream, Honey, etc.

Applicable products for Packaging :

  • Rice, Tea, Pulses, Sugar, Detergent Powder, Species, Cereals, Milk Powder, Dry Fruits, Candies etc.

Specification :

Model

CC-306

CC-307, CC-308

Bag

T:3-side F: 4-side, P : Pillow -seal

Filling method

Piston type

Suction motor

Film width (mm)

S : 50-160 M : 100-280

Bag Length (mm)

S: 50-120, M: 80-190

Hopper capacity

Suction motor

20 L

Packing Volume range

S: 2-30 cc M: 30-100 cc

Packing speed

20-80 bag/min

Motor

1/3 HP

Heater tube

150W x 2

300W x 2

Power

220 v, 50 Hz / 60 Hz 1 Ph

Machine dimensions (mm)

S: 900 x 600 x 1750 M: 900 x 700 x 1800

Packing Dimensions (mm)

S: 1000 x 700 x 1900 M: 1000 x 800 x 1950

Net weight (Kg)

320

370

Gross weight (Kg)

430

500
